February 1, 2023
4 min read

Kong Mesh & Kuma 2.1 released with full suite of next-gen policies

John Harris
Principal PM Kong Mesh & Kuma

We’re excited to announce the release of Kong Mesh and Kuma 2.1! In this release, we’re shipping the full suite of new and improved policies announced (and started) in 2.0. Additionally, we’re launching some more great UX improvements in the UI and a host of smaller fixes.

In order to take advantage of the latest and greatest in service mesh, we strongly suggest upgrading to Kong Mesh 2.1. Upgrading is simple through kumactl or Helm.

Notable features:

  • Completed implementation of all next-generation policies, adding:
    • MeshHTTPRoute
    • MeshCircuitBreaker
    • MeshFaultInjection
    • MeshHealthCheck
    • MeshOPA
    • MeshProxyPatch
    • MeshRateLimit
    • MeshRetry
    • MeshTimeout
  • Added support for header absence matching in traffic routes
  • Ability to filter admin API output
  • Added gateway view to the UI
  • Ability to filter by tags and types in the UI
  • Ability to configure ports in eBPF mode
  • Various other bug fixes and quality-of-life improvements across the product
For more details, reference the Kong Mesh Changelog.

Full Next-Generation Policy Suite

In our last major release (2.0) we released the first few policies featuring our new, more flexible, more powerful matching system. Matching is how users define which entities their policies apply to, and can get quite complex.

As a refresher, the new selectors use a targetRef system (inspired by GatewayAPI) to select which meshes, services, data plane proxies, etc. are targeted by specific policies. Multiple rules can be specified in the same policy (as supported today) or many different policies can be created targeting different subsets. With the new policy system in Mesh 2.1 the policies will be merged together in the correct precedence rules before calculating and pushing the configuration out to the Envoy dataplane.

If you want to read more about the reasoning behind switching and the design of this new policy matching system, check out the blog post Flexible Policy Match in Kuma 2.0 by our Mesh Engineering Manager Charly.

Below is an example of a new MeshHTTPRoute using targetRef selectors:

Figure 1 : Example of a next-gen MeshHTTPRoute policy

In this example, we can see that we’re applying the policy to our frontend service, and specifying that all the traffic flowing to our backend service at the /api path should be balanced between version 1.0 and 2.0 according to the weighting configuration in the policy.

While slightly more verbose than the previous TrafficRoute policy, this new selector scheme allows more flexible and granular control. Additionally, we’ll now take care of merging (according to the documented precedence rules) policies that target the same data plane proxies, rather than only choosing the most specific policy (as was the case pre v2.0).

In 2.0 we implemented 3 policies using this new matching system:

  • MeshTrafficPermission
  • MeshAccessLog
  • MeshTrafficTrace
In 2.1 we’re pleased to announce that we have completed transitioning all of the additional policies to the new system:
  • MeshHTTPRoute (partially replaces TrafficRoute)
  • MeshCircuitBreaker
  • MeshFaultInjection
  • MeshHealthCheck
  • MeshOPA
  • MeshProxyPatch (replaces ProxyTemplate)
  • MeshRateLimit
  • MeshRetry
  • MeshTimeout
Head over to the docs to check out how to use the new policies and selectors.

Continued UI & UX Improvements

In 2.1, we’re continuing our work streamlining the UX in our dashboard by simplifying the navigation options and adding various other look and feel tweaks.

[caption id="attachment_47545" align="aligncenter" width="1024"]Figure 2 : New, cleaner navigation menu Figure 2: New, cleaner navigation menu[/caption]

Having quick access to the visualization of the policies is critical for managing complex applications. In order to simplify that all of the Kong Mesh policies have been collapsed into a single Policies screen and are now accessible via a dropdown when navigating through them, as shown in Figure 2.

[caption id="attachment_47546" align="aligncenter" width="1024"]Figure 3 : Policies are now listed in a dropdown Figure 3: Policies are now listed in a dropdown[/caption]

Furthering the simplification of management, we’ve also added the ability to filter in the UI via a number of metadata fields (e.g., name, tag). These can be combined to provide very specific views of your data planes and services:

[caption id="attachment_47547" align="aligncenter" width="1024"]Figure 4 : New metadata filtering available in the UI and API Figure 4: New metadata filtering available in the UI and API[/caption]

Debugging Envoy configuration is essential when operating a mesh, so we’ve made it easy to see full XDS configuration for each data plane proxy in the UI, including a regex-enabled search capability to inspect config dump information without having to manually interact with the cluster.

[caption id="attachment_47548" align="aligncenter" width="1024"]Figure 5: Live search and debugging capabilities for Envoy data plane configuration Figure 5: Live search and debugging capabilities for Envoy data plane configuration[/caption]

We’re excited about how the UI is looking and many more UI improvements are coming in the next few releases, so stay tuned!

Get in touch with Kong to learn more about Kong Mesh and how to build an enterprise service mesh. You can also download Kong Mesh and get started for free.
