10 API Automation Methods Using Kong and AWS


← Back to Blog Home

Apps of today differ from those of the past. Evolving organizations like Cargill need to scale quickly to support millions of users, have global availability, manage petabytes or more of data and respond in milliseconds. That’s why modern apps now leverage API automation.

​​



This article will dive into applying Twelve-Factor application development principles to achieve API automation using AWS and Kong Konnect Enterprise. Using this methodology, you can make scalable and resilient apps that you can continuously deploy with maximum agility. Twelve-Factor design also lets you decouple the components of your app so that you can replace or scale each component seamlessly. Because the Twelve-Factor design principles are independent of any programming language or software stack, you can apply them to various apps or APIs going through an API gateway.

Path to API Automation Using Kong and AWS

A typical installation of Kong Konnect Enterprise on Amazon Elastic Kubernetes Service (Amazon EKS) involves installing the Kong control plane and data plane on one or more clusters across multiple availability zones or regions. You can split these between on-premise and AWS, depending on your specific use cases. Kong is a Lua application designed to load and execute Lua or Go modules or Kong plugins on the data plane. Kong provides a set of standardized Lua modules bundled with Kong Gateway.

Plugins provide advanced functionality to extend the use of Kong Gateway, which allows you to add more features to your implementation. Customers typically use Amazon services to get a better managed and highly available solution out-of-the-box. This lets Kong focus on API management and leverage AWS for non-API-management-specific activities.



AWS and Kong Architecture

1. Codebase

You must manage all the code in a central source control system and use one codebase per application. This means if you have two continuous applications in your solution, they should live in two separate codebase depositories in a version control system like Git. Storing the code in a version control system also enables your team to work together by providing an audit trail of changes to the code. It’s a systemic way of resolving conflicts and even the ability to roll back to a previous version.

Specifically for Kong, the entire infrastructure can be provisioned using AWS infrastructure as a code service. Moreover, Kong provides the ability to import the API specs directly from version control.

2. Dependencies

You should declare the application’s dependencies explicitly. No dependency can be assumed to be coming from the execution environment. In a container-based application, you can handle this by using Docker files.

A Docker file is a text-based list of instructions to create a containerized image. You can declare their application dependencies in the manifest file of the programming language’s packaging system and install them using the instructions in the file.

Specifically for Kong, it offers non-specific application-bound contexts, like compliance monitoring and logging, authentication and authorization, and traffic control, to plugins offloading these components to account. Plugins allow customers to focus on more than writing code for your specific APIs and the business facade of your interest.

3. Configurations

The deployment environment provides the specific configuration of your application using environment variables. The different stages of your deployment pipeline can provide the environment-specific configuration. You can use services like AWS AppConfig, which is a capability of AWS Systems Manager to create, manage and quickly deploy application configuration. You can use AWS AppConfig with Amazon Elastic Compute Cloud (Amazon EC2) applications, AWS Lambda functions, containers, mobile applications and even IoT devices.

Specifically for Kong infrastructure, use Helm Charts and Kubernetes manifest files to install the Kong Gateway and plugins on Amazon Elastic Kubernetes Service (Amazon EKS). Moreover, instead of using specific APIs, use the Kubernetes manifest files to deploy the Kong plugins.

4. Backing Service

Your application must treat any service that it uses to perform its business function as an attached resource. The attached resource semantics prescribes that these resources are made available to the application as a consideration. Your application will be aware of the attached resource but not tightly coupled to it.

For Kong, use managed services such as Amazon Elasticache for caching routes, discover and visualize data using ELK stack, and use Amazon Cognito for authentication and authorization.

5. Build, Release and Run

AWS CodePipeline provides a mechanism to separate the department’s build, release, and run stages, as typically recommended.

Specifically for Kong Gateway, build the API spec, fetch from the version control, use AWS CodeBuild and deploy it to the API gateway. You can orchestrate an end-to-end automation experience using AWS CodePipeline or a CI/CD tool using Kong’s Admin API



Container Specialist Solution Architect

6. Process

Since containers are stateless and immutable, you should only run one application process per container in most use cases. You must store data in a stateful service, such as a database or cache. The memory or the local disk of the execution runtime should not maintain any persistence between two incoming requests.

If you’re using Kong plugins, configure them to use the external services as applicable so that the API gateway itself stays as stateless as possible. For example, instead of using PostgreSQL DataStore locally, offload it to any available service, like Amazon Relational Database Service (Amazon RDS).

7. Port Binding

Twelve-Factor apps should be available to other applications by port binding or binding both to the execution environment. Container-based applications expose the port through the exposed command instructions in the Docker file.

For Kong, use AWS elastic load balancer to expose the API gateway proxy manager portal, ensuring that these components are accessible at different ports.

8. Concurrency

Container-based applications can scale out by spinning up more instances of the container process.

Kong can use a horizontal pod auto scaler to scale out the control plane and data plane based on the incoming traffic.

9. Logs

Treating logs as a continuous system of events instead of static files allows you to react to the continuous nature of log generation. You can capture, store and analyze real-time logs to get meaningful insights into applications, performance, network and other characteristics. An application must not be required to manage its own log files.

For Kong, you can use the plugins that empower customers to send TCP logs, UDP logs, CIS logs and all the relevant metrics associated with your specific API.

10. Admin Processes

Any admin or maintenance task for the application should run in an identical environment to that of the application. These maintenance tasks are usually short-running and only intended to support the normal business functions of the main application.

Specifically for Kong, use admin API for admin functions and limit the admin APIs bound by authentication and authorization against the respective datastore.

Try Out Kong on AWS EKS

See how easy it is to run API automation on Kong and AWS. Kong accelerates moving mission-critical services to the AWS cloud by reducing disruption to the business during and after migration. Kong also enables AWS integration to legacy, on-premise systems that were not designed to handle cloud-volume requests. Kong works with Amazon EKS, AWS Lambda, Amazon Elastic Container Service (Amazon ECS), Amazon RDS, Amazon Aurora, Amazon ElastiCache and more.
